Introduction
8-Hi Strip Rolling Mill is driven by support roller, deviated from the work roll bearing roll center installation. So that the reduction of the diameter of the work rolls is not limited by the torque, and is not affected by horizontal bending. Therefore, the work roll diameter can be small, usually half of the four-roll mill work roll diameter, this off-set 8 hi rolling mill can meet the requirements of rolling thin steel and rolling difficult-to-deform products like the cluster mill.
Parameters
Production Line Process Parameters
Rolling Speed(m/s) | 500 Strip Mill | 650 Strip Mill | 750 Strip Mill | 850 Strip Mill | 1150 Strip Mill | 1450 Strip Mill |
Input Thickness | 0.6-1.2mm | 0.6-1.2mm | 0.6-1.2mm | 0.6-1.2mm | 1.0-2.5mm | 1.0-2.5mm |
Outputt thickness | 0.1-0.3mm | 0.15-0.3mm | 0.15-0.3mm | 0.15-0.3mmm | 0.2-0.6mm | 0.2-0.6mm |
Strip Width | 300-420mm | 400-580mm | 500-670mm | 600-750mm | 850-1000mm | 1000-1250mm |
Transmission | Working Roll | Working Roll | Working Roll | Working Roll | ||
Rolling Force | 3000KN | 7000KN | 8000KN | 9000KN | 12000KN | 16000KN |
Rolling Speed(m/s) | 3000KN | 7000KN | 8000KN | 9000KN | 12000KN | 16000KN |
Features
1. Compared with the 4-hi rolling mill, the off-set 8-hi rolling mill requires the rolling force only half of the 4-hi rolling mill.
2. The off-set 8-Hi mill with a rigid structure of the larger roller system and roll shaped adjusting device. Which can be rolled out the strip steel with thickness deviation smaller and flat shape straight.
