200,000 Tons Stainless Steel Wire Rod Mill Line Project For Mumbai Area, IndiaAuthor : hani Time : 2018/04/03
- Project: 200,000 Tons Wire Rod Mill Line, the main equipment is the Morgan type 10 stands finishing mill (customer original bar mill line 14-32mm, now want to increase the wire rod mill line 5.5-13.5mm)
- Rolled Steel Type: Stainless Steel
- Rolling Speed: 70m/s
- Finish Rolling Section Shrinkage 1.18
- Annual Output 200,000 tons/year
- Billet size: 125*140*9000mm
- Passes: A total of 32 passes (22 stands roughing rolling mill + 10 stands finishing rolling mill)
The Composition of Finishing Mill
Type: The pre-finishing mill is composed of continuous horizontal and vertical alternately arranged. The vertical rolling mill is an upper drive.
The finishing mill consists of a continuous 45-degree top-crossing 10 heavy-duty, non-twist finishing mills.
The mill model is a Morgan finishing mill model.
The main rolling mill includes: pre-finishing unit Φ285-finishing unit Φ230-Φ1700 rolling mill
Wire Rod Mill Laying Head
Position: After the pinch roll.
Function: It is used to turn the wire rod into a coil and place it on the conveying roller of the roll cooling conveyor.
Structure: The laying head is a horizontal laying head, the laying pipe is fixed on the spinning disc, the spinning disc is driven by the electric motor through the gearbox, and the transmission gears are hard tooth surfaces.
The Main Technical Parameters:
Wire rod mill laying head tilt angle: 15°
Wire diameter: φ5.5～φ16mm
Spitting circle diameter: φ1070mm
Pinching roll/laying head unit lubrication method: concentrated oil lubrication
The protective cover is pneumatic: the cylinder model is QGBII200x610-MP2
